Illustrated Guide to the National Electrical Code

by Charles R. Miller

Providing a unique approach to learning the Code, the Illustrated Guide to the NEC uses highly detailed, technically accurate illustrations and visuals to break down and simplify the expanding volume and complexity of the 2008 National Electrical Code. By translating the sometimes vague, complicated wording of the Code into straightforward illustrations and clear explanations, this book provides a resource that will facilitate comprehension and application of Code requirements for beginning and master electricians alike. Material is organized logically, covering fundamental provisions first, and then grouping code requirements by the type of occupancy, beginning with one-family dwellings, and progressing on to multi-family, commercial locations, and special occupancies. This organization is not only logical but also reflects how information is needed when working in the electrical industry, better preparing readers for the real world. Its comprehensive coverage, innovative learning approach, and industry-based organization make this an indispensable supplement to the NEC, whether users need information on a specific area, or need to learn the Code from cover to cover.

480 pages, Paperback

First published March 25, 1999

Reviews

[Hom Sack · Rating 5 out of 5]

A delightful read if you're into subjects like these. Certainly better than reading the code itself, although relevant sections are referenced. Just be mindful that this edition refers to the 2014 code ( updated every three years ) and is currently good for states like Pennsylvania but not for Massachusetts which now uses the 2020 Edition of the code. But I suspect for typical residential work, the 2014 Edition is sufficient.

[Harry Harman]

For eighteen years, Charles R. Miller owned and operated a successful commercial electrical contracting company

Congress created the Occupational Safety and Health Administration (OSHA) in the early 1970s

Intertek’s comprehensive program includes testing, listing, labeling, and quarterly follow-up inspections.

Branch circuits are divided into four categories: appliance, general purpose, individual, and multiwire.
