Textbook of Computer Aided Machine Drawing: Using Solid Edge Commands for 2-D; 3-D and Assembly Drawings

by Murthy

The Salient features of books are : Use of latest B/S Conventions.Prepared in First angle projection only Incorporates updated information from industries Special treatise on chapter Section plares using colour illustrations. Unique presentation of Assembly drawings through 3-D pictorial as well as 3-D exploded pictorial assembly drawings. Presents Standard assumptions in case of incomplete data. Extensive use of Hints and Notes to clear all doubts and ambiguities about the subject as well as solving the problems. Step-by-step demonstrative approach similarto that of classroom teaching. To build self-confidence in solving a variety of problems.

290 pages, Paperback

Published September 12, 2008
